PRODUCT INFORMATION
Installation
Desktop
Dimensions (L*W*H)
100*100*26mm
Application Scenario
Office,Home,School,Retail,CCTV,etc.
Operation Mode
Router Mode
PERFORMANCE PARAMETERS
Max. Client Capacity
150
Recommended Client Capacity
100
Recommended Broadband
1000Mbps
Max. New Sessions
4000
Max. Concurrent Sessions
42000
NAT (Static IP)
940Mbps/930Mbps
NAT(DHCP)
941Mbps/932Mbps
NAT(PPPoE)
914Mbps/924Mbps
AP Management
16
VLAN
4
HARDWARE PARAMETERS
CPU
Dual Cor 1.0GHz
RAM
128 MB
FLASH
16 MB
Ports
5*GE (Max. 4 WAN, Max. 4 LAN)
PoE Outport
802.3af/at on LAN1-4
PoE Budget
55W
Button
Reset Button
Standards and Protocols
IEEE 802.3, 802.3u, 802.3x, TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, DDNS
Power Supply
51VDC/1.25A Adapter
SOFTWARE PARAMETERS(ROUTER)
AP Management
16APs
DHCP Server
DHCP Server(User/AP),DHCP Reservation
Wireless Policy
AP Group,SSID Policy,RF Policy,Vlan Policy,maintenance policy,Alarm Policy,Deployment Policy
Fast Roaming
802.11k,v,r
IPTV
IPTV Policy
ACL
IP/MAC/URL/PORT
Bandwidth Control
Based on single user, user group, smart bandwidth control
VPN
IPSec, PPTP, L2TP
Virtual Server
DMZ, DDNS, DNS Hijacking,IP Hijacking,UPNP,Port Mirroring,Port Mapping,DNS Cache
IPV6
Support
WAN Load Balancing
Intelligent Load Balancing,Customize
Routing
Static Routing,Policy Routing
Security
IP-MAC binding, Block Ping from WAN,DDoS Attack Defense,ARP Attack Defense,Binary Association
System Tools
ntp,Scheduled reboot, Diagnosis
System Log
system log,Operating log,Running log
System Account
Administrator,Visitor,Login IP Address Limit
Upgrade
Local,Online
Maintenance
Restore,Backup,Remote WEB Management
Management
http/https
SOFTWARE PARAMETERS(AC)
Software Parameters(AC)
AP Management
DHCP Server
Wireless Policy
Fast Roaming
IPTV
Security
System Tools
System Log
System Account
Upgrade
Maintenance
Management
OTHER PARAMETERS
Environment
Operating Temperature: -10 ℃ -45 ° C
Operating Humidity:10%-90% RH, non-condensing
Storage Temperature: -40°C-70°C
Storage Humidity: 5%-90% RH, non-condensing
