TEG1126P-24-410W is a unmanaged PoE switch independently designed by Tenda. Compliant with IEEE 802.3af and IEEE 802.3at standards, it can identify PoE-powered devices intelligently. With a maximum PoE power output of 370 W, and 30 W for a single port, it can supply power when transmitting data with APs, IP cameras, and IP phones. The switch supports 4 working modes, including standard, priority, extend and VLAN modes, which is an ideal choice for SMBs, hotels, schools, factories with video surveillance and wireless networking requirements.
Highlights:
Compliant with IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3x and IEEE802.3af/at standards.
24 * 100/100 0Mbps Base-T RJ45 ports for data transmission and power supply, 2 * 1000 Mbps Base-X SFP slots（Combo）.
8K MAC address table and MAC address auto-learning.
IEEE 802.3x-compliant full-duplex flow control and half-duplex backpressure flow control.
48Gbps backplane bandwidth.
Maximum power consumption of a single port: 30W; Maximum power consumption of the switch: 410W.
4 modes: standard, priority, extend and VLAN.
TEG1118P-16-250W is a unmanaged PoE switch independently designed by Tenda. Compliant with IEEE 802.3af and IEEE 802.3at standards, it can identify PoE-powered devices intelligently. With a maximum PoE power output of 230W, and 30W for a single port, it can supply power when transmitting data with APs, IP cameras, and IP phones. The switch supports 4 working modes, including standard, priority, extend and VLAN modes, is an ideal choice for SMBs, hotels, schools, factories with video surveillance and wireless networking requirements.
Highlights:
Compliant with IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3x and IEEE802.3af/at standards.
16 * 100/1000 Mbps Base-T RJ45 ports for data transmission and power supply, 2* 1000 Mbps Base-X SFP slot.
8K MAC address table and MAC address auto-learning.
IEEE 802.3x-compliant full-duplex flow control and half-duplex backpressure flow control.
36Gbps backplane bandwidth.
Maximum power consumption of a single port: 30W; Maximum power consumption of the switch: 250W.
4 modes: standard, priority, extend and VLAN.
Specifications:
Standards: IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3x, IEEE802.3af/at
LEDs indicator:
16 * Link/Act LEDs
2 * SFP LED
1 * PoE-MAX LED
1 * Power LED
Interfaces:
16 * 100/1000 Mbps Base-T RJ45 ports (Data/Power)
2* 1000 Mbps Base-X SFP port
Forwarding Rates: 26.8Mpps
Switching capacity: 36Gbps
MAC Address Table: 8K
Lightning protection: ≥6KV
Input voltage: AC: 100-240V~50/60Hz
PoE supply:
Ports 1-16 support standard IEEE802.3af/at
30W output per PoE port
230W output of the total PoE Power
Power consumption: 250W output the whole device
Dimensions: 440*178.8*44mm
Four Modes:
Standard: Default mode of the switch. In this mode, it works as an unmanaged switch; all ports can communicate with each other separately.
Priority: In this mode, port15,16, SFP1, SFP2 serve as uplink ports, ports 1 – 8 serve as high priority port. All ports can communicate with each other separately.
Extend: In this mode, data rate of ports 9 - 14 reduces to 10 Mbps, the maximum transmission distance can be 250 meters, and all ports can communicate with each other.
VLAN: In this mode, ports 1 - 14 of the switch can communicate with port 14,15, SFP1, SFP2 separately, but cannot communicate with each other. You can enable this mode to reduce broadcast storm and isolate DHCP broadcast.
Environment:
Operating Temperature: 0℃~45℃ (32℉~113℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
TEG1124P-24-250W is a Tenda PoE switch that offers 24 10/100/1000 Mbps Base-TX RJ45 ports. Ports 1-24 comply with the IEEE 802.3af standard (maximum PoE power output: 15.4W) and 802.3at standard (maximum PoE power output: 30W). The switch provides a maximum PoE power output of 225W and can supply power to and exchange data with APs, IP cameras, and IP phones through CAT5 cables. It also provides simple management modes such as CCTV, VLAN, and Isolation to help reduce cabling costs of IP terminals like APs and IP cameras.
Highlights:
Offers 24 x 10/100/1000 BASE-T ports (Data/Power)
Maximum PoE output power of up to 225W and up to 30W per PoE port
Provides simple management modes such as CCTV, VLAN, and Isolation
Ports 1-24 comply with the IEEE802.3af and IEEE802.3at power supply standards
6KV lightning protection for ports
TEG1116P-16-150W is a Tenda PoE switch that offers 16 10/100/1000 Mbps Base-TX RJ45 ports. Ports 1-16 comply with the IEEE 802.3af standard (maximum PoE power output: 15.4 W) and 802.3at standard (maximum PoE power output: 30 W). The switch offers a maximum PoE power output of 135 W and can supply power to and exchange data with APs, IP cameras, and IP phones through CAT5 cables. It also provides simple management modes such as CCTV, VLAN, and Isolation to help reduce cabling costs of IP terminals like APs and IP cameras.
Highlights:
16*10/100/1000Mbps Base-TX RJ45 ports
Ports 1-16: IEEE802.3af/at PoE ports
Maximum power output of the switch: 135W
13-inch desktop size: 1U height, rack mountable
Hardware DIP switch for selection among the standard, CCTV, VLAN, and Isolation modes.
Hardware DIP switch to VLAN ports to prevent broadcast storm and defend against DHCP spoofing.
TEG1109P-8-102W is the gigabit unmanaged lightning protection switch which is Tenda specifically developed for the requirement of building Gigabit WLAN and HD camera monitor network. With high-performance access, 9-10/100/1000M Base-T Ethernet RJ45 ports; 6KV lightning-proof for uplink port; every single port support MDI/MDIX and wired speed; PoE ports supports IEEE802.3at/af standard while detecting and recognizing the IEEE802.3at/af standard power device automatically. Through conventional Cat 5e twisted-pair cable, power can be transmitted along with data for AP, IP Camera and IP Phone. With PoE dynamic power, easier configure, flexible extend network without being limited by the power line layout, plug and play, helping SMB, hotel, shopping mall, school to build high-security and reliability network of wireless cover and HD monitor.
Highlights:
6KV lightning protection
One-key VLAN
Intelligent 8-core power supply
Smart power management
Large buffer design
TEF1118P-16-150W is an unmanaged PoE switch independently designed by Tenda. Compliant with IEEE 802.3af and IEEE 802.3at standards, it can identify PoE-powered devices intelligently. With a maximum power output of 150 W, and 30 W for a single port, it can supply power when transmitting data with APs, IP cameras, and IP phones. The switch supports 4 working modes, including standard, priority, extend and VLAN modes, which is an ideal choice for SMBs, hotels, schools, factories with video surveillance and wireless networking requirements.
Highlights:
Compliant with IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3x and IEEE802.3af/at standards.
16 * 10/100 Mbps Base-TX RJ45 ports for data transmission and power supply, 2 * 10/100/1000 Mbps Base-T RJ45 ports for data transmission, 1 * 10/100/1000 Mbps Base-X combo SFP slot.
4 K MAC address table and MAC address auto-learning.
IEEE 802.3x-compliant full-duplex flow control and half-duplex backpressure flow control.
7.2 Gbps backplane bandwidth.
Maximum power consumption of a single port: 30W; Maximum power consumption of the switch: 150W.
2.75 MB cache size for smooth video surveillance.
4 modes: standard, priority, extend and VLAN.
Desktop and rack mounting.
Specifications:
Standards: IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3x, IEEE802.3af/at
LEDs indicator:
16 * Link/Act LEDs
1 * G1 LED
1 * G2/SFP2 LED
1 * PoE-MAX LED
1 * Power LED
Interfaces:
16 * 10/100 Mbps Base-TX RJ45 ports (Data/Power)
2 * 10/100/1000 Mbps Base-T RJ45 ports (Data)
1 * 10/100/1000 Mbps Base-X SFP port (Combo)
Forwarding Rates: 5.36 Mpps
Switching capacity: 7.2 Gbps
MAC Address Table: 4K
Lightning protection: ≥6KV
Input voltage: AC: 100-240V~50/60Hz
PoE supply:
Ports 1-16 support standard IEEE802.3af/at
30W output per PoE port
130W output of the total PoE Power
Power consumption: 150W output the whole device
Dimensions: 294*178.8*44mm
Four Modes:
Standard: Default mode of the switch. In this mode, it works as an unmanaged switch; all ports can communicate with each other separately.
Priority: In this mode, port G1 and G2/SFP2 serve as uplink ports, ports 1 – 8 serve as high priority port. All ports can communicate with each other separately.
Extend: In this mode, data rate of ports 9 - 16 reduces to 10 Mbps, the maximum transmission distance can be 250 meters, and all ports can communicate with each other.
VLAN: In this mode, ports 1 - 16 of the switch can communicate with port G1, G2/SFP2 separately, but cannot communicate with each other. You can enable this mode to reduce broadcast storm and isolate DHCP broadcast.
Environment:
Operating Temperature: 0℃~45℃ (32℉~113℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Tenda TEF1109P-8-63W, Unmanaged, Fast Ethernet (10/100), Power over Ethernet (PoE), Rack mounting. Lead security transmission power supply to a higher level TEF1109P-8-63W 9-Port 10/100Mbps Desktop Switch With 8-Port PoE 6KV Lightning Protection long distance transmission Maximum PoE Output Power 58W PoE power up to 30W for each PoE port.
Highlights:
Eight PoE ports for simplified connectivity and power efficiency
Enhanced network security with advanced PoE management features
Compact desktop design ideal for space-constrained environments
Specifications:
HARDWARE
Network standards
IEEE 802.3、 IEEE 802.3u、IEEE 802.3x、IEEE 802.3af、IEEE 802.3at
LED Indicator
9 * Link/Ack LED indicators
1 * Power LED indicator
Interfaces
8*10/100 Base-TX Ethernet ports (Data/Power)
1*10/100 Base-TX Ethernet ports (Data)
Transmission media
Recommended: CAT5/5e UTP or better
Dimension
177.5mmx104.0mmx26.0mm
Level of protection
Lightning protection for ports: 6KV
Lightning protection for power: 4KV
ESD:
Air discharge: ±10kV
Contact discharge: ±8kV
Forwarding mode
Store-and-forward
Switch capacity
1.8 Gbit/s
Packet forwarding rate
1.34Mpps
Buffer
1.25Mb
MAC address table
4K
PoE budget
Single port: AF: 15.4W, AT: 30W
Whole device: 58W
Input voltage
100－240V AC 50/60Hz
51V /1.25A DC（Power Adapter ）
Mounting
Desktop mounting: support
Wall mounting: support
Rack mounting:non-support
Environment
Operating Temperature: 0℃~45℃
Storage Temperature: -40℃~70℃
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Certification
FCC、CE、RoHS
SOFTWARE
Functions
Standard: the switch functions as a common unmanaged switch and all the ports of the switch can communicate with each other.
VLAN: ports 1 to 8 are isolated from each other, but can communicate with ports 9 (uplink port) respectively.
TEF1106P-4-63W is an unmanaged PoE switch with 2 uplink ports, independently designed by Tenda. Compliant with IEEE 802.3at/af standards, it can identify PoE-powered devices intelligently. The switch supplies a maximum PoE power output of 63 W, and 30 W for a single port. Featured with extended mode and QoS function, TEF1106P-4-63W is an ideal choice for SMBs, supermarkets and restaurants with small-sized video surveillance requirements.
Highlights:
6KV lightning protection
250m extend mode
QoS
Dual uplink ports
4-Port PoE
TEF1105P-4-63W is a Tenda PoE switch that offers 5 10/100 Mbps Base-TX RJ45 ports. Up to 250 meters long distance transmission, beyond a hundred meters transfer limit. 6KV lightning protection PoE switch is the real monitoring private switch. Ports 1-4 support IEEE 802.3at and IEEE 802.3af PoE standard. It provides 30W maximum PoE output a single port and 58W the whole device.
Highlights:
5*10/100 Mbps Base-TX RJ45 port; Ports 1-4: IEEE 802.3af/at PoE ports
Maximum power output of each PoE port: 30W; maximum power output of the switch: 58W Desktop size, metal case, Power Adapter Output 63W.
Support extend mode, the transmission distance of both power and data will extend up to 250m
Specifications:
HARDWARE
Network standards
IEEE 802.3、 IEEE 802.3u、IEEE 802.3x、IEEE 802.3af、IEEE 802.3at
LED Indicator
5* Link/Ack LED indicators
1 * Power LED indicator
Interfaces
4*10/100 Base-TX Ethernet Ports(Data/Power)
1*10/100 Base-TX Ethernet Port(Data)
Transmission media
Recommended: CAT5/5e UTP or better
Dimension
100.0mmx100.0mmx26.0mm
Level of protection
Lightning protection for ports: 6kV
Lightning protection for power: 6kV
ESD:
Air discharge: ±10kV
Contact discharge: ±8kV
Forwarding mode
Store-and-forward
Switch capacity
1Gbps
Packet forwarding rate
0.74Mpps
Buffer
448K
MAC address table
1K
PoE budget
Single port: AF: 15.4W, AT: 30W
Whole device: 58W
Input voltage
100－240V AC 50/60Hz
51V /1.25A DC（Power Adapter ）
Mounting
Desktop mounting: support
Wall mounting: support
Rack mounting:non-support
Environment
Operating Temperature: 0℃~45℃
Storage Temperature: -40℃~70℃
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Certification
FCC、CE、RoHS
SOFTWARE
Functions
Standard: the switch functions as a common unmanaged switch and all the ports of the switch can communicate with each other.
Extend Mode: If the extend mode is enabled, the transmission distance of both power and data will extend up to 250m(10Mbps), this funcation can replace the extender and parts of the Fiber. It will extend the distance of the whole system and save the cost of the project.
TEM2010F is an 8-port 2.5G Ethernet switch with 2 SFP ports independently designed by Tenda. The switch supports three-mode toggle and offers eight 2.5 Gbps RJ-45 ports and two 2.5 Gbps SFP ports, establishing high-speed network along with computers, NAS, TV set-up boxes, Wi-Fi6 APs and so on. TEM2010F is an ideal access device for high-speed network deployment in SMEs, SOHOs, villas or wireless networking scenarios.
Highlights:
Compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3bz, IEEE 802.3cb.
8*100/1000/2500 Mbps Base-TX Ethernet ports, 2*100/1000/2500 Mbps Base-X SFP ports
16 K MAC address table and MAC address auto learning.
IEEE 802.3x full duplex flow control and half duplex backpressure flow control
50Gbps switching fabric for non-blocking wire speed forwarding
6kV Lightning Protection
Three-mode toggle: Standard, VLAN, Static Aggregation Desktop mounting & Wall mounting
Specifications:
Network Standards: IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x, IEEE802.3bz，IEEE 802.3cb
(MTBF)/MTBF: ≥100,000 hours
LED Indicators:
Two Link/Act LED indicators for each port
One Power LED indicator for each device
Ports:
8*100/1000/2500 Mbps Base-TX Ethernet ports
2*100/1000/2500 Mbps Base-X SFP ports
Lightning Protection: ≥6 kV
Forwarding Mode: Store and forward
Switching Capacity: 50Gbps
Forwarding Rate: 37.2Mpps
MAC Address Table: 16K
Input Voltage: AC: 100-240V 50Hz/60Hz
Dimensions (L × W × H): 220mm*135.6mm*31.5mm（L*W*H）
Three-mode Toggle:
Three-mode toggle through one DIP switch:
1. Standard: In this mode, all ports can communicate with each other.
2. VLAN: Ports 1-6 are isolated from each other but can communicate with ports 7-10
3. Static Aggregation: Group 1: 7-8; Group 2: 9-10. For dual-port 2.5G NAS, up to 5 Gbps
Environment:
Operating temperature: 0°C - 45°C
Storage temperature: -40°C - 70°C
Operating humidity: (10% - 90%) RH, non-condensing
Storage humidity: (5% - 90%) RH, non-condensing
