Description
i27 is designed based on the new Wi-Fi 6 technology. It realizes a bandwidth of 160 MHz and a 5 GHz rate as high as 2.4 Gbps, a rate three times higher than that of ordinary Wi-Fi 5 APs and two times that of ordinary Wi-Fi 6 APs. The application of such new technologies as OFDMA, spatial multiplexing, and MU-MIMO drives the network capacity of a single i27 to 4 times higher. i27 is a perfect choice for such locations as businesses and hotels to deploy high-performance Wi-Fi networks.
Highlights:
- Up to 3000 Mbps dual-band data rate
- The new WPA3 encryption mode safeguards your network security
- OFDMA, UL/DL and MU-MIMO technologies provide higher client capacity
- Seamless roaming guarantees no dropped voice or video calls even when moving
Specifications:
- Category: Ceiling
- Dimensions: 178mm * 38mm
- Frequency band: 2.4 GHz, 5 GHz
- Wireless standards: IEEE 802.11a/b/g/n/ac/ax
- 2.4 GHz data rate: 1-574 Mbps
- 5 GHz data rate: 6-2402 Mbps
- Channel width: 20 MHz/40 MHz/80 MHz/160 MHz
- MU-MIMO: 2X2 MU-MIMO
- Ethernet port: One 10/100/1000 Mbps Ethernet Port (PoE)
- LED indicator: RGB
- Max. power consumption: 13.04W
- Power supply standard: IEEE 802.3at PoE
- Concurrent clients: 254
- Antenna gain: 2*4dBi
- 2.4 GHz Max. output power: 27+/-1.5 dBm
- 5 GHz Max. output power: 26+/-1.5 dBm
- 802.11b RX sensitivity: -99 dBm
- 2.4 GHz 802.11n (MCS7) RX sensitivity: -78 dBm
- 5 GHz 802.11a RX sensitivity: -97 dBm
- 5 GHz 802.11n (MCS7) RX sensitivity: -77 dBm
- Operating mode: AP、AP + Client
- Hide SSID: Supported
- Max. No. of SSID: 2.4 GHz: 8 / 5 GHz: 8
- OFDMA: Supported
- Beamforming: Supported
- TWT: Supported
- Fast roaming: Supported
- 802.11 k/v: Supported
- WPA3-ASE: AES
- WPA2-PSK: AES/TKIP
- WPA2: Supported
- Access control: MAC address-based
- Adjustable power transmission: Supported
- Frequency analysis: Supported
- AP isolation: Supported
- Connected client control: Supported
- RSSI threshold: Supported
- VLAN tagging for SSID: Supported
- LED indicator control: Supported
- Diagnostics tool: Ping, Traceroute
- Scheduled reboot: Supported
- Reboot at specified interval: Supported
- Default login IP address: 192.168.0.254
- Default username/password: admin/admin
- Operating temperature: -10℃ - 45℃
- Operating humidity: (10% - 90%) RH, non-condensing
- Storage temperature: -30℃ - 70℃
- Storage humidity: (10% - 90%) RH, non-condensing
